Monocular tube inclined upto 90°
Achromatic Objectives 4x, 10x & 40x (SL)
WF 10x & H5x or H15x
Six stop Dial Diaphragm with Single Lens Condenser N.A. 0.65
Specifications
Observation head : Monocular tube inclined upto 90°
Eyepiece : WF 10x
Stage : Plane Stage With Stage Clips
Condenser : Six stop Dial Diaphragm with Single Lens Condenser N.A. 0.65
Focusing : Separate Coarse & Fine Focusing Adjustment
Objectives : Achromatic Objectives 4x, 10x & 40x (SL)
Eyepiece : WF 10x & H5x or H15x
Nosepiece : Triple Revolving Nose Piece
Safety Device : Adjustable down stopper for preventing accidental damage to slides
Illumination : 42mm Plano-concave Mirror
Safety device : Adjustable down stopper for preventing accidental damage to slides
Packing : Full moulded thermocol container
Warranty 1 Year
1000x power biological microscope with fully coated glass optics
10x eyepiece with 4x, 10x, 40x and 100x objective lenses
Metal body with 360° rotatable monocular head
Mechanical stage, Abbe condenser, iris diaphragm, coarse and fine focusing knobs and 4.5 volt LED illumination
Specifications
Body : Stable and robust, assembled from alluminium die cast parts
Head : Vertical Monocular Head
Observation head : Monocular tube inclined upto 90°
Eyepiece : WF 10x
Stage : Fixed square stage size 120x120mm with stage clips
Objectives : Achromatic objective 10x & 40x (SL)
Nosepiece : Triple Revolving Nosepiece with precise centering and positive click stops.
Safety Device : Adjustable down stopper for preventing accidental damage to slides
Illumination : Plano concave mirror dia 50mm mounted on a gimble
Packing : Full moulded thermocol container
Optional Accessories : 1. Sub stage pin type lamp working on 220 volts -15 watts.
2. Mechnical stage for X - Y movements of slide.
3. Wooden Box with lock and key.
4. Objective 4x
Warranty 1 Year
1000x power biological microscope with fully coated glass optics
10x eyepiece with 4x, 10x, 40x and 100x objective lenses
Metal body with 360° rotatable monocular head
Mechanical stage, Abbe condenser, iris diaphragm, coarse and fine focusing knobs and 4.5 volt LED illumination
Five prepared slides included
Specifications
Body : Stable and robust, assembled from alluminium die cast parts
Head : Monocular Head, 45° Inclined, 360° Rotatable
Observation head : Monocular head 45° inclined 360° rotatable
Eyepiece : WF 10x
Stage : Fixed square stage size 120x120mm with stage clips
Objectives : Achromatic objective 10x & 40x (SL)
Nosepiece : Triple Revolving Nosepiece with precise centering and positive click stops.
Safety Device : Adjustable down stopper for preventing accidental damage to slides
Illumination : Plano concave mirror dia 50mm mounted on a gimble
Packing : Full moulded thermocol container
Optional Accessories : 1. Sub stage pin type lamp working on 220 volts -15 watts.
2. Mechnical stage for X - Y movements of slide.
3. Wooden Box with lock and key.
4. Objective 4x
Warranty 1 Year
1000x power biological microscope with fully coated glass optics
10x eyepiece with 4x, 10x, 40x and 100x objective lenses
Metal body with 360° rotatable monocular head
Mechanical stage, Abbe condenser, iris diaphragm, coarse and fine focusing knobs and 4.5 volt LED illumination
Specifications
Body : Stable and robust, assembled from alluminium die cast parts
Head : Monocular Head, 45° Inclined, 360° Rotatable
Observation head : Monocular head 45° inclined 360° rotatable
Eyepiece : WF 10x
Stage : Fixed square stage size 120x120mm with stage clips
Objectives : Achromatic objective 10x & 40x (SL)
Nosepiece : Triple Revolving Nosepiece with precise centering and positive click stops.
Safety Device : Adjustable down stopper for preventing accidental damage to slides
Illumination : Plano concave mirror dia 50mm mounted on a gimble
Packing : Full moulded thermocol container
Optional Accessories : 1. Sub stage pin type lamp working on 220 volts -15 watts.
2. Mechnical stage for X - Y movements of slide.
3. Wooden Box with lock and key.
4. Objective 4x
Warranty 1 Year
Aluminium die cast parts with all critical movements, based on ball-bearing guides
Sidentop Monocular head 30° inclined, 360° rotatable
SEMIPLAN objectives 4x, 10x 40x (SL) and 100x (SL) OIL (Anti fungus)
6V 20W Halogen bulb with variable illumination control
Specifications
Body : Aluminium die cast parts with all critical movements, based on ball-bearing guides
Observation head : Binocular head 45° inclined 360° rotatable
Stage : Co-axial double plate mechanical stage with ball bearing slides for frictionless and jerk free movement
Condenser : Moveable condenser (NA 1.2) with IRIS diahragm and filter holder on rack and pinion
Focusing : Coaxial Coarse and Fine focusing machanism
Objectives : SEMIPLAN objectives 4x, 10x 40x (SL) and 100x (SL) OIL (Anti fungus)
Eyepiece : WF 10x (F. no. 18) (Pair).
Nosepiece : Quadruple ball bearing nosepiece with rubber grip for long-life smooth rotation.
Safety Device : Adjustable down stopper for preventing accidental damage to slides
Illumination : 6V 20W Halogen bulb with variable illumination control
Packing : Full moulded thermocol container
Optional Accessories : 1. DIN Plan Achromatic objectives 4x, 10x, 40x (SL) and 100x (SL) OIL
2. LED illumination System
3. Phase contrast attachment
Warranty 1 Year
Aluminium die cast parts with all critical movements, based on ball-bearing guides
Sidentop Monocular head 30° inclined, 360° rotatable
SEMIPLAN objectives 4x, 10x 40x (SL) and 100x (SL) OIL (Anti fungus)
6V 20W Halogen bulb with variable illumination control
Specifications
Body : Aluminium die cast parts with all critical movements, based on ball-bearing guides
Observation head : Trinocular head 45° inclined 360° rotatable
Stage : Co-axial double plate mechanical stage with ball bearing slides for frictionless and jerk free movement
Condenser : Moveable condenser (NA 1.2) with IRIS diahragm and filter holder on rack and pinion
Focusing : Coaxial Coarse and Fine focusing machanism
Objectives : SEMIPLAN objectives 4x, 10x 40x (SL) and 100x (SL) OIL (Anti fungus)
Eyepiece : WF 10x (F. no. 18) (Pair).
Nosepiece : Quadruple ball bearing nosepiece with rubber grip for long-life smooth rotation.
Safety Device : Adjustable down stopper for preventing accidental damage to slides
Illumination : 6V 20W Halogen bulb with variable illumination control
Packing : Full moulded thermocol container
Optional Accessories : 1. DIN Plan Achromatic objectives 4x, 10x, 40x (SL) and 100x (SL) OIL
2. LED illumination System
3. Phase contrast attachment
Warranty 1 Year
Aluminium die cast parts with all critical movements, based on ball-bearing guides
Sidentop Monocular head 30° inclined, 360° rotatable
SEMIPLAN objectives 4x, 10x 40x (SL) and 100x (SL) OIL (Anti fungus)
6V 20W Halogen bulb with variable illumination control
Specifications
Body : Aluminium die cast parts with all critical movements, based on ball-bearing guides
Observation head : Sidentop Binocular head 30° inclined 360° rotatable
Stage : Co-axial double plate mechanical stage with ball bearing slides for frictionless and jerk free movement
Condenser : Moveable condenser (NA 1.2) with IRIS diahragm and filter holder on rack and pinion
Focusing : Coaxial Coarse and Fine focusing machanism
Objectives : SEMIPLAN objectives 4x, 10x 40x (SL) and 100x (SL) OIL (Anti fungus)
Eyepiece : WF 10x (F. no. 18) (Pair).
Nosepiece : Quadruple ball bearing nosepiece with rubber grip for long-life smooth rotation.
Safety Device : Adjustable down stopper for preventing accidental damage to slides
Illumination : 6V 20W Halogen bulb with variable illumination control
Packing : Full moulded thermocol container
Optional Accessories : 1. DIN Plan Achromatic objectives 4x, 10x, 40x (SL) and 100x (SL) OIL
2. LED illumination System
3. Phase contrast attachment
Warranty 1 Year
Aluminium die cast parts with all critical movements, based on ball-bearing guides
WF 10x (F. no. 18) (Pair)
SEMIPLAN objectives 4x, 10x 40x (SL) and 100x (SL) OIL (Anti fungus)
Adjustable down stopper for preventing accidental damage to slides
Specifications
Body : Aluminium die cast parts with all critical movements, based on ball-bearing guides
Observation head : Sidentop Trinocular head 30° inclined 360° rotatable
Stage : Co-axial double plate mechanical stage with ball bearing slides for frictionless and jerk free movement
Condenser : Moveable condenser (NA 1.2) with IRIS diahragm and filter holder on rack and pinion
Focusing : Coaxial Coarse and Fine focusing machanism
Objectives : SEMIPLAN objectives 4x, 10x 40x (SL) and 100x (SL) OIL (Anti fungus)
Eyepiece : WF 10x (F. no. 18) (Pair).
Nosepiece : Quadruple ball bearing nosepiece with rubber grip for long-life smooth rotation.
Safety Device : Adjustable down stopper for preventing accidental damage to slides
Illumination : 6V 20W Halogen bulb with variable illumination control
Packing : Full moulded thermocol container
Optional Accessories : 1. DIN Plan Achromatic objectives 4x, 10x, 40x (SL) and 100x (SL) OIL
2. LED illumination System
3. Phase contrast attachment
Warranty 1 Year
Plane Stage With Stage Clips
Achromatic Objectives 4x, 10x & 40x (SL)
42mm Plano-concave Mirror
Adjustable down stopper for preventing accidental damage to slides
Specifications
Observation head : Monocular Head 45° Inclined 360° RotatableWarranty 1 Year
Eyepiece WF 10x & H5x or H15x
Triple revolving nosepiece with precise centering and positive click stops
Adjustable down stopper for preventing accidental damage to slides
Detachable Mechnical stage with Moveable condenser (NA 1.2) with IRIS diahragm and filter holder on rack and pinion)
Specifications
Stand : Aluminium die cast partsWarranty 1 Year
Eyepiece WF 10x & H5x
Triple revolving nosepiece with precise centering and positive click stops
Adjustable down stopper for preventing accidental damage to slides
Detachable Mechnical stage with Moveable condenser (NA 1.2) with IRIS diahragm and filter holder on rack and pinion)
Specifications
Stand : Aluminium die cast partsWarranty 1 Year
1000x power biological microscope with fully coated glass optics
10x eyepiece with 4x, 10x, 40x and 100x objective lenses
Metal body with 360° rotatable monocular head
Mechanical stage, Abbe condenser, iris diaphragm, coarse and fine focusing knobs and 4.5 volt LED illumination
Specifications
Body : Aluminiumu die cast parts with all critical movements, based on ball-bearing guidesWarranty 1 Year
1000x power biological microscope with fully coated glass optics
10x eyepiece with 4x, 10x, 40x and 100x objective lenses
Metal body with 360° rotatable monocular head
Mechanical stage, Abbe condenser, iris diaphragm, coarse and fine focusing knobs and 4.5 volt LED illumination
Five prepared slides included
Specifications
Body : Aluminiumu die cast parts with all critical movements, based on ball-bearing guidesWarranty 1 Year
1000x power biological microscope with fully coated glass optics
10x eyepiece with 4x, 10x, 40x and 100x objective lenses
Metal body with 360° rotatable monocular head
Mechanical stage, Abbe condenser, iris diaphragm, coarse and fine focusing knobs and 4.5 volt LED illumination
Specifications
Body : Aluminiumu die cast partsWarranty 1 Year
1000x power biological microscope with fully coated glass optics
10x eyepiece with 4x, 10x, 40x and 100x objective lenses
Metal body with 360° rotatable monocular head
Mechanical stage, Abbe condenser, iris diaphragm, coarse and fine focusing knobs and 4.5 volt LED illumination
Five prepared slides included
Specifications
Body : Aluminiumu die cast partsWarranty 1 Year
